SolaRISE (30W-40W) - Outdoor Street Lighting Solutions - Wipro Lighting
SolaRISE (30W-40W) - Outdoor Street Lighting Solutions - Wipro Lighting
Streetlights

SolaRISE (30W-40W)

30W-40W

Compact, Aesthetic, Ecofriendly & Modern integrated solar streetlight in extruded aluminium construction with high efficiency monocrystalline silicon photo voltaic panel, High Efficacy SMD LED 6500K having secondary lens optics for street lighting distribution, high performance lithium battery, MPPT charge controller and intelligent control module/sensor with higher reliability, long service life, suitable for easy and quick installation.

Best Suited for

  • Parks
  • Perimeter Lighting
  • Hotels
  • Green Building
  • Schools
  • Resorts
  • Campus Lighting
  • Street Lighting
  • Pathway Lighting
  • Security Lighting
  • Yard Lighting
  • Remote Area Lighting
  • Military Base Lighting
  • Smart Cities
  • Industrial

PRODUCT DETAILS

State-of-the-art lighting solutions with best-in-class features.

FEATURES & BENEFITS

LED

The LEDs use special lenses providing better optics and street lighting distribution. Available in different wattages, these streetlights are perfectly suited for a variety of applications.

Mono-Crystalline Silicone Solar Panel

The mono crystalline panel top efficiency, enhances the energy conversion rate in the streetlight. It helps in faster charging and increasing the overall efficiency.

Lithium Ferro-Phosphate Battery

The streetlights use high power compact design, high performance lithium iron phosphate batteries which are tested to perform under high temperatures. These also have higher life span of up to 2000 cycles as compared to the regular offering around 500 to 1000 charging cycles.

Intelligent Controller and Sensor

The efficiency of the street lights is maximised using a sensor and an intelligent controller, which is programmed to regulate the light output depending on movement detection and time schedule.

The streetlight usually operates on 30% intensity, and glows with full intensity when the sensors detect movement. Time schedule model operates on 100X intensity for first 3 hours, 65X intensity for next 2 hours and for rest of the time at 30X intensity.

SPECIFICATIONS
  • Aesthetic and compact design in extruded aluminium construction
  • 30W | 60W monocrystalline silicon panel & 30 [15x2] W LED
  • 40W | 80W monocrystalline silicon panel & 40 [20x2] W LED
  • CRI >80, lighting efficiency upto 120 Lm/W, CCT – 6000 to 6500 Deg K
  • 30W | 12.8V 28Ah Lithium Ferro Phosphate (LifePo4) battery
  • 40W | 12.8V 35Ah Lithium Ferro Phosphate (LifePo4) battery
  • Full Power upto 12 hrs; Saving mode upto 48 hrs
  • Integral PIR sensor
  • MPPT charge controller with 90 to 96% efficiency
ELECTRICAL & PACKAGING
ELECTRICAL DATA
System Voltage
12V/24V
Output Power
50W/12V, 100W/24V
Output Current
0.15A – 3.3A
No load loss
9mA/12V, 12mA/24V
Charging Current
15A
Solar Input Voltage
< 55V
Over Voltage Protection
16V, x 2/24V
Charging Voltage Limit
15.5V, x2/24V
PRODUCT CODE & DIMENSIONS
LR14-441-XXX-65-XX
30W
1120 x 305 x 140 mm
LR14-591-XXX-65-XX
40W
1120 x 305 x 140 mm
All dimensions are in mm. Tolerance: ± 2mm
Solar & LED are ever improving & evolving technologies. Wipro is committed to bring you the best in Solar & LED technologies.
INSTALLATION
  • Pole Height Recommendations:
    30W | 6-7m | 40W | 6-7m
  • Suitable for external pipe dia of 40 to100 mm
*Also available in other CCT options.
*Hybrid (AC-DC) option available on request.
